Vertical rectangular manways

(36)

Stainless steel rectangular manways in vertical version, designed for installation in tanks or other industrial equipment.

New product
Special-purpose manway W2/A/PE (530x406)

Special-purpose manway

W2/A/PE (530x406)

  • Vertical rectangular manway
  • Pressure up to 0.9 bar
  • Cover on two hinges with handwheels
  • Mounting in the side wall of polyethylene tanks
  • Made of stainless steel AISI 304L or AISI 316L
  • Flange and counter flange bent to tank diameter
  • Gasket material: EPDM, silicone, NBR or Viton
From stock
Rectangular manway W2/A (530x406)

Rectangular manway

W2/A (530x406)

  • Vertical rectangular manway
  • Pressure up to 1.1 bar (depending on version)
  • Hinged cover with two handwheels
  • Mounting in the roof or in the side wall of the tank
  • Made of stainless steel AISI 304L or AISI 316L
  • Basic versions available from stock
  • Gasket material: EPDM, silicone, NBR or Viton
Rectangular manway E115 (530x406)

Rectangular manway

E115 (530x406)

  • Vertical manway

  • Opening to the outside

  • Pressure from 0.9 to 1.1 bar (depending on version)
  • Two hinges, two handwheels
Special-purpose manway E115CEM (530x406)

Special-purpose manway

E115CEM (530x406)

  • Vertical manway

  • Opening to the outside

  • Two hinges, two handwheels
  • Mounting in the side wall of the tank
  • Made of stainless steel AISI 304L or AISI 316L
  • Gasket material: EPDM, silicone, NBR or Viton
  • Version for mounting in concrete/cement tanks
Special-purpose manway E130CEM (424x316)

Special-purpose manway

E130CEM (424x316)

  • Vertical manway

  • Opening to the inside

  • Mounting in the side wall of the tank
  • Made of stainless steel AISI 304L or AISI 316L
  • Gasket material: EPDM, silicone, NBR or Viton
  • Version for mounting in concrete/cement tanks
Special-purpose manway E121CEM (424x316)

Special-purpose manway

E121CEM (424x316)

  • Vertical manway

  • Opening to the outside

  • Two hinges, two handwheels
  • Mounting in the side wall of the tank
  • Made of stainless steel AISI 304L or AISI 316L
  • Gasket material: EPDM, silicone, NBR or Viton
  • Version for mounting in concrete/cement tanks
Rectangular manway E121 (424x316)

Rectangular manway

E121 (424x316)

  • Pressure from 1.0 to 1.2 bar (depending on version)
  • Vertical mounting
  • Opening to the outside
  • Two hinges, two handwheels
Rectangular manway E123 (424x316)

Rectangular manway

E123 (424x316)

  • Pressure up to 0.7 bar
  • Vertical mounting
  • Opening to the outside
  • Two hinges, one handwheel
Rectangular manway E129 (530x406)

Rectangular manway

E129 (530x406)

  • Pressure up to 1.8 bar
  • Vertical mounting
  • Opening to the inside
  • One hinge, two handwheels
Rectangular manway E130 (424x316)

Rectangular manway

E130 (424x316)

  • Pressure up to 2.0 bar
  • Vertical mounting
  • Opening to the inside
  • Internal hinge
Rectangular manway E131 (424x316)

Rectangular manway

E131 (424x316)

  • Pressure up to 2.0 bar
  • Vertical mounting
  • Opening to the inside
  • External hinge
Rectangular manway E132 (450x750)

Rectangular manway

E132 (450x750)

  • Pressure up to 1.5 bar
  • Vertical mounting
  • Opening to the outside
  • Two external hinges, six handwheels
  • Mounting in stainless steel tanks and silos
Rectangular manway E133 (600x800)

Rectangular manway

E133 (600x800)

  • Pressure up to 1.5 bar
  • Vertical mounting
  • Opening to the outside
  • Two external hinges, six handwheels
  • Mounting in stainless steel tanks
Rectangular manway A362 (530x400)

Rectangular manway

A362 (530x400)

  • Pressure up to 1.0 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Two hinges and handwheels
  • Gasket mounted in the cover
Rectangular manway A362V (530x400)

Rectangular manway

A362V (530x400)

  • Pressure up to 1.0 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Removable cover
  • Two-sided tightening with four handwheels
  • Gasket mounted in the cover
Rectangular manway A362R (530x400)

Rectangular manway

A362R (530x400)

  • Pressure up to 2.5 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Two hinges
  • Cover with multipoint clamping
  • Gasket mounted in the cover
Rectangular manway A364 (530x400)

Rectangular manway

A364 (530x400)

  • Pressure up to 1.0 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the inside
  • Cover with two internal hinges and two handwheels
  • Gasket mounted in the cover
Rectangular manway A372 (420x310)

Rectangular manway

A372 (420x310)

  • Pressure up to 0.8 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Two hinges and handwheels
  • Gasket mounted in the cover
Rectangular manway A374 (420x310)

Rectangular manway

A374 (420x310)

  • Pressure up to 1.0 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the inside
  • Cover with two internal hinges and one handwheel
  • Gasket mounted in the cover
Rectangular manway E129/1 (530x406)

Rectangular manway

E129/1 (530x406)

  • Pressure up to 1.8 bar
  • Vertical mounting
  • Opening to the inside
  • Cover with one hinge and two handwheels
  • Possibility to rotate the cover when opened
Rectangular manway A375 (420x310)

Rectangular manway

A375 (420x310)

  • Pressure up to 0.8 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Cover with two hinges and one handwheel
  • Gasket mounted in the cover
Rectangular manway A381 (225x175)

Rectangular manway

A381 (225x175)

  • Pressure up to 0.7 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Cover with hinge and handwheel
  • Gasket mounted in the cover
Rectangular manway A382 (310x245)

Rectangular manway

A382 (310x245)

  • Pressure up to 0.5 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Cover with hinge and handwheel
  • Gasket mounted in the cover
Rectangular manway A383 (365x275)

Rectangular manway

A383 (365x275)

  • Pressure up to 0.4 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Cover with two hinges and handwheels
  • Gasket mounted in the cover
Rectangular manway A384 (405x275)

Rectangular manway

A384 (405x275)

  • Pressure up to 0.4 bar
  • Vertical mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Cover with two hinges and handwheels
  • Gasket mounted in the cover
Rectangular manway A392 (MAX 2000x2000)

Rectangular manway

A392 (MAX 2000x2000)

  • Inspection and/or evacuation manway
  • Horizontal or vertical mounting (depending on version)
  • Opening to the outside
  • Custom production according to project requirements
  • Gasket mounted in the cover
  • Optional: version for cement/concrete tanks
Rectangular manway A651 (225x175)

Rectangular manway

A651 (225x175)

  • Pressure up to 0.3 bar
  • Vertical mounting
  • Mounting in the roof of the tank
  • Opening to the outside
  • Removable cover with two handwheels
  • Gasket mounted in the cover
Rectangular manway A652 (310x245)

Rectangular manway

A652 (310x245)

  • Pressure up to 0.3 bar
  • Vertical mounting
  • Mounting in the roof of the tank
  • Opening to the outside
  • Removable cover with two handwheels
  • Gasket mounted in the cover
Rectangular manway A653 (360x275)

Rectangular manway

A653 (360x275)

  • Pressure up to 0.1 bar
  • Vertical mounting
  • Mounting in the roof of the tank
  • Opening to the outside
  • Removable cover with two handwheels
  • Gasket mounted in the cover
Rectangular manway A654 (400x280)

Rectangular manway

A654 (400x280)

  • Pressure up to 0.1 bar
  • Vertical mounting
  • Mounting in the roof of the tank
  • Opening to the outside
  • Removable cover with two handwheels
  • Gasket mounted in the cover
Rectangular manway P13-105 (314x424)

Rectangular manway

P13-105 (314x424)

  • Mounting in the side wall of the tank
  • Pressure up to 1.3 bar
  • Vertical mounting
  • Opening to the inside
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: standard / polishing / electropolishing
Rectangular manway P13-409 (410x534)

Rectangular manway

P13-409 (410x534)

  • Mounting in the side wall of the tank
  • Pressure up to 1.0 bar
  • Manway in horizontal or vertical version
  • Opening to the inside
  • Two handwheels
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: standard / polishing / electropolishing
Rectangular manway P23-210 (314x424)

Rectangular manway

P23-210 (314x424)

  • Mounting in the side wall of the tank
  • Pressure up to 0.8 bar
  • Manway in horizontal or vertical version
  • Opening to the outside
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: standard / polishing / electropolishing
Rectangular manway P23-307 (314x424 / 534x410)

Rectangular manway

P23-307 (314x424 / 534x410)

  • Mounting in the side wall of the tank
  • Pressure up to 0.3 bar
  • Manway in horizontal or vertical version
  • Opening to the outside
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: standard / polishing / electropolishing
  • Available dimensions: 314x424 / 534x410
Rectangular manway P23-111 (410x534)

Rectangular manway

P23-111 (410x534)

  • Mounting in the side wall of the tank
  • Pressure up to 0.6 bar
  • Manway in horizontal or vertical version
  • Opening to the outside
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: standard / polishing / electropolishing
Rectangular manway P23-201 (314x424 / 410x534)

Rectangular manway

P23-201 (314x424 / 410x534)

  • Mounting in the side wall of the tank
  • Pressure up to 1.6 bar (depending on version)
  • Manway in horizontal or vertical version
  • Opening to the outside
  • Multi-point cover closure
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: polishing / electropolishing
  • Available dimensions: 314x424 / 410x534
