Horizontal rectangular manways

(27)

Rectangular stainless steel manways in horizontal version, designed for installation in tanks or other industrial equipment.

From stock
Rectangular manway W2/D (424x316)

Rectangular manway

W2/D (424x316)

  • Horizontal rectangular manway
  • Pressure up to 0.7 bar
  • Hinged cover with one handwheel
  • Mounting in the side wall of the tank
  • Made of stainless steel AISI 304L or AISI 316L
  • Basic versions available from stock
  • Gasket material: EPDM, silicone, NBR or Viton
From stock
Rectangular manway W2/E (175x225)

Rectangular manway

W2/E (175x225)

  • Horizontal rectangular manway
  • Pressure up to 0.7 bar
  • Hinged cover with one handwheel
  • Mounting in the roof or in the side wall of the tank
  • Made of stainless steel AISI 304 or AISI 316
  • Basic versions available from stock
  • Gasket material: EPDM, silicone, NBR or Viton
From stock
Rectangular manway W2/F (245x310)

Rectangular manway

W2/F (245x310)

  • Horizontal rectangular manway
  • Pressure up to 0.5 bar
  • Hinged cover with one handwheel
  • Mounting in the roof or in the side wall of the tank
  • Made of stainless steel AISI 304 or AISI 316
  • Basic versions available from stock
  • Gasket material: EPDM, silicone, NBR or Viton
Rectangular manway E116 (406x530)

Rectangular manway

E116 (406x530)

  • Horizontal manway
  • Opening to the outside

  • Pressure from 0.8 to 1.8 bar (depending on version)
  • Two hinges, two handwheels
Rectangular manway E122 (316x424)

Rectangular manway

E122 (316x424)

  • Pressure from 1.0 to 1.2 bar (depending on version)
  • Horizontal mounting
  • Opening to the outside
  • Two hinges, two handwheels
Rectangular manway E124 (316x424)

Rectangular manway

E124 (316x424)

  • Pressure up to 0.7 bar
  • Horizontal mounting
  • Opening to the outside
  • Two hinges, one handwheel
Rectangular manway A363 (400x530)

Rectangular manway

A363 (400x530)

  • Pressure up to 1.0 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Two hinges and handwheels
  • Gasket mounted in the cover
Rectangular manway A363BV (400x530)

Rectangular manway

A363BV (400x530)

  • Pressure up to 0.3 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Removable cover
  • Two handwheels
  • Gasket mounted in the cover
Rectangular manway A363R (400x530)

Rectangular manway

A363R (400x530)

  • Pressure up to 2.5 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Two hinges
  • Cover with multipoint clamping
  • Gasket mounted in the cover
Rectangular manway A363V (400x530)

Rectangular manway

A363V (400x530)

  • Pressure up to 0.3 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Removable cover
  • Two-sided tightening with four handwheels
  • Gasket mounted in the cover
Rectangular manway A363B (400x530)

Rectangular manway

A363B (400x530)

  • Pressure up to 0.3 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Hinged cover with one handwheel
  • Gasket mounted in the cover
Rectangular manway A373 (310x420)

Rectangular manway

A373 (310x420)

  • Pressure up to 0.8 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Hinged cover with one handwheel
  • Gasket mounted in the cover
Rectangular manway A376 (310x420)

Rectangular manway

A376 (310x420)

  • ​​​​​​Pressure up to 0.8 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Cover with two hinges and one handwheel
  • Gasket mounted in the cover
Rectangular manway A381L (175x225)

Rectangular manway

A381L (175x225)

  • Pressure up to 0.7 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Cover with hinge and handwheel
  • Gasket mounted in the cover
Rectangular manway A382L (245x310)

Rectangular manway

A382L (245x310)

  • Pressure up to 0.5 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Cover with hinge and handwheel
  • Gasket mounted in the cover
Rectangular manway A383L (275x365)

Rectangular manway

A383L (275x365)

  • Pressure up to 0.3 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Cover with hinge and handwheel
  • Gasket mounted in the cover
Rectangular manway A384L (275x405)

Rectangular manway

A384L (275x405)

  • Pressure up to 0.3 bar
  • Horizontal mounting
  • Mounting in the side wall of the tank
  • Opening to the outside
  • Cover with hinge and handwheel
  • Gasket mounted in the cover
Rectangular manway A392 (MAX 2000x2000)

Rectangular manway

A392 (MAX 2000x2000)

  • Inspection and/or evacuation manway
  • Horizontal or vertical mounting (depending on version)
  • Opening to the outside
  • Custom production according to project requirements
  • Gasket mounted in the cover
  • Optional: version for cement/concrete tanks
Rectangular manway A651L (175x225)

Rectangular manway

A651L (175x225)

  • Pressure up to 0.3 bar
  • Horizontal mounting
  • Mounting in the roof of the tank
  • Opening to the outside
  • Removable cover with two handwheels
  • Gasket mounted in the cover
Rectangular manway A652L (245x310)

Rectangular manway

A652L (245x310)

  • Pressure up to 0.3 bar
  • Horizontal mounting
  • Mounting in the roof of the tank
  • Opening to the outside
  • Removable cover with two handwheels
  • Gasket mounted in the cover
Rectangular manway A653L (275x360)

Rectangular manway

A653L (275x360)

  • Pressure up to 0.1 bar
  • Horizontal mounting
  • Mounting in the roof of the tank
  • Opening to the outside
  • Removable cover with two handwheels
  • Gasket mounted in the cover
Rectangular manway A654L (280x400)

Rectangular manway

A654L (280x400)

  • Pressure up to 0.1 bar
  • Horizontal mounting
  • Mounting in the roof of the tank
  • Opening to the outside
  • Removable cover with two handwheels
  • Gasket mounted in the cover
Rectangular manway P13-409 (410x534)

Rectangular manway

P13-409 (410x534)

  • Mounting in the side wall of the tank
  • Pressure up to 1.0 bar
  • Manway in horizontal or vertical version
  • Opening to the inside
  • Two handwheels
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: standard / polishing / electropolishing
Rectangular manway P23-210 (314x424)

Rectangular manway

P23-210 (314x424)

  • Mounting in the side wall of the tank
  • Pressure up to 0.8 bar
  • Manway in horizontal or vertical version
  • Opening to the outside
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: standard / polishing / electropolishing
Rectangular manway P23-307 (314x424 / 534x410)

Rectangular manway

P23-307 (314x424 / 534x410)

  • Mounting in the side wall of the tank
  • Pressure up to 0.3 bar
  • Manway in horizontal or vertical version
  • Opening to the outside
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: standard / polishing / electropolishing
  • Available dimensions: 314x424 / 534x410
Rectangular manway P23-111 (410x534)

Rectangular manway

P23-111 (410x534)

  • Mounting in the side wall of the tank
  • Pressure up to 0.6 bar
  • Manway in horizontal or vertical version
  • Opening to the outside
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: standard / polishing / electropolishing
Rectangular manway P23-201 (314x424 / 410x534)

Rectangular manway

P23-201 (314x424 / 410x534)

  • Mounting in the side wall of the tank
  • Pressure up to 1.6 bar (depending on version)
  • Manway in horizontal or vertical version
  • Opening to the outside
  • Multi-point cover closure
  • Gasket mounted in the cover
  • Gasket material: EPDM, neoprene, silicone (also HT - high temperature), NBR, Viton and other
  • Custom version: ATEX (requires individual consultation)
  • Surface finish options: polishing / electropolishing
  • Available dimensions: 314x424 / 410x534
